◆ Rated Load 30A
◆ Extended temp. range up to 125℃
◆ Plastic sealed and dust proof types available
◆ ELV compliant
| Specifications | ||
| Contact | Contact Form | 1H |
| Rated Load (Resistive property) |
NO:30A 12VDC | |
| Electrical/Mechanical Life | ≥100000times/10000000times | |
| Initial Contact Resistance | ≤50MΩ (1A 6VDC) | |
| Contact Material | AgSnO₂ | |
| Charact eristics | Insulation Resistance | ≥1000MΩ (500VDC) |
| Dielectric Strength | Between open contacts≥500VAC/1min | |
| Between contact and coil≥500VAC/1min | ||
| Operate/Release Time | ≤15ms/10ms | |
| Terminal Type | Quick Connection | |
| Coil | Operating Power DC | 1.8W |
| DC Coil Data | |||
| Rated Voltage VDC |
Pickup Voltage VDC |
Dropoff Voltage VDC |
Coil Resistance Ω±10% |
| 5 | 3.5 | 0.5 | 16 |
| 6 | 4.2 | 0.6 | 20 |
| 12 | 8.4 | 1.2 | 85 |
| 24 | 16.8 | 2.4 | 320 |
