Features
◆ Fast response
◆ Slim size
◆ Rated Load.1Z 12A, 2Z 8A
| Specifications | |||
| Contact | Contact Form | 1Z | 2Z |
| Rated Load | 12A 250VAC/30VDC | 8A 250VAC/30VDC | |
| Electrical/Mechanical Life | ≥100000times/10000000times | ||
| Initial Contact Resistance | ≤100MΩ (1A 6VDC) | ||
| Contact Material | AgSnO₂ AgNi | ||
| Charact eristics | Insulation Resistance | ≤500MΩ (500VDC) | |
| Dielectric Strength | Between open contacts≥1000VAC/1min | ||
| Between poles≥1500VAC/1min | |||
| Between contact and coil≥4000VAC/1min | |||
| Operate/Release Time | ≤15ms/15ms | ||
| Terminal Type | Plug in | ||
| Coil | Operating Power DC/AC | 0.53W/0.9VA | |
| DC Coil Data | |||
| Rated Voltage VDC |
Pickup Voltage VDC |
Dropoff Voltage VDC |
Coil Resistance Ω±10% |
| 3 | 2.25 | 0.3 | 17 |
| 5 | 3.75 | 0.5 | 47 |
| 6 | 4.5 | 0.6 | 68 |
| 9 | 6.75 | 0.9 | 150 |
| 12 | 9.0 | 1.2 | 270 |
| 18 | 13.5 | 1.8 | 610 |
| 24 | 18.0 | 2.4 | 1100 |
| 48 | 36.0 | 4.8 | 4220 |
| 110 | 82.5 | 11.0 | 22800 |
| AC Coil Data | |||
| Rated Voltage VAC |
Pickup Voltage VAC |
Dropoff Voltage VAC |
Coil Resistance Ω±10% |
| 6 | 4.8 | 1.8 | 16 |
| 12 | 9.6 | 3.6 | 65 |
| 24 | 19.2 | 4.2 | 240 |
| 48 | 38.4 | 14.4 | 1080 |
| 115 | 88 | 33.0 | 6300 |
| 230 | 184 | 69.0 | 23000 |
