| Specifications | ||||
| Rated Load | Current/Voltage | A/VAC | 16/300 | 10/300 |
| Dielectric Strength | Coil & Contacts | V/S | 4000 | |
| Between contacts | V/S | 2500 | ||
| Wire Size | AWG/mm2 | 20-14/0.5-2.5 | ||
| Tightening Torque | Nm | 0.8 | ||
| Terminal Ingress Protection | IP20 | |||
| Matched Accessories | |||
| Socket | Clip | Module | DIN Rail |
| PRF05A-E | B-25S (Pre-configured) |
/ |  |
| PRF05A-E | |||
